首頁歐美晶振 ILSI晶振美國ILSI晶振|ISA12-3EAH-28.800 MHz|耐高溫振蕩器

美國ILSI晶振|ISA12-3EAH-28.800 MHz|耐高溫振蕩器

頻率：28.8MHz
尺寸：2.5×2.0mm
應　用： 美國ILSI晶振,ISA12進口有源晶振,石英晶振,ISA12-3EAH-28.800 MHz晶振,2520mm晶振,晶體振蕩器,四腳貼片晶振,頻率28.8MHz,電壓3.3V,工作溫度-40~105°C,頻率穩定性25ppm,LVCMOS兼容輸出,耐高溫晶振,耐老化晶振,儀表盤晶...

美國ILSI晶振|ISA12-3EAH-28.800 MHz|耐高溫振蕩器,美國ILSI晶振,ISA12進口有源晶振,石英晶振,ISA12-3EAH-28.800 MHz晶振,2520mm晶振,晶體振蕩器,四腳貼片晶振,頻率28.8MHz,電壓3.3V,工作溫度-40~105°C,頻率穩定性25ppm,LVCMOS兼容輸出,耐高溫晶振,耐老化晶振,儀表盤晶振,TPMS晶振,GPS導航晶振,ADAS應用晶振.
美國ILSI晶振|ISA12-3EAH-28.800 MHz|耐高溫振蕩器特點
●通過AEC-Q200認證
●通過TS16949認證的生產線
●LVCMOS兼容輸出
●行業標準包裝2.5mm x 2.0mm
●五種電源電壓選擇，1.8V, 2.5V, 2.8V, 3.0V或3.3V
●無鉛、無鹵、無銻
●符合RoHS和REACH標準

美國ILSI晶振|ISA12-3EAH-28.800 MHz|耐高溫振蕩器規格表

Frequency Range

28.8 MHz

Frequency Stability

±50ppm Maximum
±100ppm Maximum

Inclusive of Initial Tolerance, Stability over Operating Temperature Range, Load (±5%), Voltage (±10%), and Aging (First Year at +25°C)

Operating Temperature Range

-40°C to +85°C
-40°C to +105°C
-40°C to +125°C

Supply Voltage (Vdd)

1.8V
2.5V, 2.8V, 3.0V or 3.3V

±5%
±10%

Input Current

20mA Maximum

No Load

Output Logic Type

LVCMOS

Output Drive Capability

15pF Maximum

Aging

±3ppm/year Maximum

at +25°C

Duty Cycle

50 ±5(%)

Measured at 50% of waveform

Rise / Fall Time

6nSec Maximum

Measured from 20% to 80% of waveform

Output Voltage Logic High

90% of Vdd Minimum

Output Voltage Logic Low

10% of Vdd Maximum

Input Voltage Logic High

70% of Vdd Minimum or No Connect to Enable Output

Input Voltage Logic Low

30% of Vdd Maximum to Disable Output (High Impedance)

Standby Current

10µA Maximum

Disabled Output, High Impedance

Startup Time

10mSec Maximum

RMS Period Jitter

5pSec Maximum
6pSec Maximum

Vdd = 2.5V, 2.8V, 3.0V or 3.3V
Vdd = 1.8V

Peak-to-Peak Period Jitter

30pSec Maximum
40pSec Maximum

Vdd = 2.5V, 2.8V, 3.0V or 3.3V
Vdd = 1.8V

NOTES: ● All minimum and maximum limits are specified over temperature and rated operating voltage with 15pF output unless otherwise stated.
● A 0.1µF bypass capacitor is recommended between Vdd (pad 4) and GND (pad 2) to minimize power supply noise.

美國ILSI晶振|ISA12-3EAH-28.800 MHz|耐高溫振蕩器尺寸圖
