XTCLH20M000TJEB7P0晶体振荡器使用特点
来源：http://m.hneyq.com 作者：亿金电子 2019年03月25
村田是日本有名的电子元件制造商,所生产的陶瓷晶体谐振器,陶瓷晶振名列世界前排,高质量的产品获得业界一致认可,是诸多客户指定品牌.村田晶振集团拥有先进的生产技术,为了更好的服务广大用户,村田陶瓷晶振推出石英晶体谐振器,石英晶体振荡器,包括TCXO和VC-TCXO振荡器.
村田提供广泛的TCXO晶振产品阵容（温度补偿晶体振荡器）/VCTCXO（电压控制温度补偿晶体振荡器）,使用了高可靠性的晶体谐振器、卓越的温度补偿方法和调整方法,是村田经过多次试验结合多年的经验所研发制造.
| 村田晶振 | 频率 | 频率公差 | 工作温度范围 |
| XNCHH10M000TJEA2P0晶振 | 10.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH15M300TJEA0P0有源晶振 | 15.3000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| 村田XNCHH16M368TJEA4P0晶振 | 16.3680MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH16M800TJEA3P0贴片晶振 | 16.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH19M200TJEC1P0石英晶振 | 19.2000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH26M000TJEE5P0晶振 | 26.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH28M800TJEA1P0晶体振荡器 | 28.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH32M000TJEB5P0 | 32.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH38M400TJEB3P0工业晶振 | 38.4000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCHH52M000TJEA1P0进口有源晶振 | 52.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCJH10M000TJEA8P0贴片晶振 | 10.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCJH15M300TJEA0P0石英晶振 | 15.3000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCJH16M800TJEA1P0石英晶体最大的器 | 16.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCJH19M200TJEA5P0石英晶振 | 19.2000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCJH26M000TJEB4P0晶振 | 26.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| 村田XNCJH28M800TJEA1P0晶振 | 28.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| 日本XNCJH38M400TJEA3P0进口晶振 | 38.4000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XNCJH52M000TJEA0P0有源晶振 | 52.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH10M000TJEA3P0有源晶体振荡器 | 10.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH15M300TJEA2P0贴片晶振 | 15.3000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH16M800TJEA2P0石英晶振 | 16.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH19M200TJEB4P0晶振 | 19.2000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH20M950TJEA0P0晶体振荡器 | 20.9500MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH21M250TJEA0P0石英晶振 | 21.2500MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH26M000TJEB1P0晶振 | 26.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH28M800TJEA0P0石英晶振 | 28.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH38M400TJEA1P0贴片晶振 | 38.4000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCHH52M000TJEA1P0石英晶体振荡器 | 52.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH10M000TJEB0P0贴片晶振 | 10.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH15M300TJEA3P0有源晶振 | 15.3000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH16M800TJEB0P0晶振 | 16.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH19M200TJEB6P0贴片晶振 | 19.2000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH26M000TJEB4P0石英晶振 | 26.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH28M800TJEA0P0晶振 | 28.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH38M400TJEA3P0进口晶振 | 38.4000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCJH52M000TJEA5P0贴片晶振 | 52.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH10M000TJEB4P0石英晶振 | 10.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH13M000TJEA3P0有源晶振 | 13.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH16M800TJED2P0有源晶体振荡器 | 16.8000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH19M200TJEC4P0贴片晶振 | 19.2000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH19M200TJJC3P0日本进口晶振 | 19.2000MHz | ±0.5ppmmax. (25±3℃) | -40℃ to 85℃ |
| XTCLH20M000TJEB7P0日产有源晶振 | 20.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH21M250TJEA0P0村田石英晶振 | 21.2500MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH25M000TJJA5P0村田晶振 | 25.0000MHz | ±0.5ppmmax. (25±3℃) | -40℃ to 85℃ |
| XTCLH26M000TJEA7P0村田贴片晶振 | 26.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH26M000TJJA6P0村田有源晶振 | 26.0000MHz | ±0.5ppmmax. (25±3℃) | -40℃ to 85℃ |
| XTCLH38M400TJEA0P0村田晶体振荡器 | 38.4000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
| XTCLH40M000TJEB0P0晶振 | 40.0000MHz | ±1ppmmax. (25±3℃) | -30℃ to 85℃ |
村田晶体振荡器使用特征
1.具有优良的高温频率稳定性
2.小尺寸,厚度薄
3.具有低电源电压
4.SMD型（可回流焊接）自动贴片机上锡高效
5.村田有源晶振产品符合RoHS指令,不含铅.
村田晶体振荡器应用
1.商业无线电装置
2.全球定位系统（全球导航卫星系统）
3.小型基站,移动通信设备
4.无线设备,无线蓝牙
